TECHNICAL DATA
| Mains voltage | 3~ NPE 230/400V |
|---|---|
| Mains Frequency | 50/60 Hz |
| AC input current in A effectiv | 15,5 A |
| Mains fuse | 16,0 A |
| Nominal Power | 9600,0 W |
| Power Factor (pf) | 0,94 |
| Duty Cycle | 100,0 % |
| Residual current Circuit Breaker | B |
| Minimum Mains Lead Cross Section | 2,5 m2 |
| Nominal output voltage | 48,0 V |
| Output Voltage Range | 2-69,6V |
| Charging current / output current nominal | 160,0 A |
| Dimension / l | 633,0 mm |
| Dimension / h | 344,0 mm |
| Weight | 22,6 kg |
| Ambient Temperature Range | -20°C / +40°C |
| Maximum Altitude above Sea level | 2000m |
| Protection class | 20,0 |
| Test symbol | CE |
